Self- adhesive 13.56Mhz PET NFC label
Round self- adhesive 3M glue 13.56Mhz pet NFC label RFID HF sticker with printing
- Feature
- Parameter
- Details
FEATURE
Waterproof
Reprintable with custom logo
Excellent reading performance
The PET NFC label is optional for CMYK printing, one color printing the custom logo
Our professional production team support personalisation printing requirement, such as UID printing, Serial number printing and QR code etc. The NXP NTAG424 chip has 50 year data retention and 416 Bytes of user memory, the powerful and advance AES-128 security features suit the needs for product authentication and anti-counterfeit.
PARAMETER
| PROPERTY | DETAIL |
|---|---|
| Antenna size | 35*22mm |
| Label die-cut | 40*25mm (minimum), support custom size |
| City/reel | 2500pcs |
| Core ID | 76mm/3inch |
| Substrate | PET |
| Face Material | PET Optional: coated paper, PVC, synthetic paper |
| Unique Print | Logo & ID & QR Print Available |
| Adhesive | Yes, Permanent |
| Re-Printing Option | Thermal Transfer |
| Frequency | 13.56MHz |
| Protocol | ISO/IEC14443Type-A |
| IC | NXPNATG424DNA |
| UID | 7byteUID |
| Memory | 416 bytes(User) |
| Data Retention | 50years (estimated) |
| Write endurance | 200.000 cycles |
| Security | EA14.AES-128.SUN message |
